Roller crusher
The roller crusher is used to crush materials whose compressive strength under 300Mpa, with moisture below 35% all kinds ore, rock materials intermediate crushing and fine crushing, such as iron ore, quartz stone, ceramic original materials etc.
Roller crusher application
The rollers crusher is widely used for secondary and fine crushing in the industry of mining, building materials, chemical industry, metallurgy and so on. It can crush materials in middle hardness such as rocks, ore, coke, lump coal, slag, mineral slag, cement clinker, fireproof materials, and so on.
Roller crusher features
1. With the advanced hydraulic control system, users can adjust the pressure according to the material hardness, so that can press and pulverize the materials absolutely;
2. With sensor, the machine can load relief when overloaded, so to protect the machine;
3. The advanced hard-faced technology improves the roller covers’ life;
4 . Good performance, low cost in operation and easy maintenance.
Specifications of roller crusher
| Model | Feeding Size (mm) | Output Size (mm) | Capacity (t/h) | Motor Power (kw) | Weight (t) | Overall Dimension (mm) |
| 2PG1000×700 | <100 | ≤3-30 | 20-68 | 2×30 | 14.9 | 5310×2175×1595 |
| 2PY1200×800 | <120 | ≤3-35 | 35-84 | 2×37 | 25.5 | 6290×2270×1870 |
| 2PG1500×800 | <130 | ≤3-45 | 50-125 | 2×75 | 33.7 | 7460×2410×2290 |
| 2PG1600×1000 | <150 | ≤3-50 | 60-146 | 2×90 | 41.2 | 8220×2680×2475 |
